This is a modern, space-optimized 3-Bedroom, 3-Bathroom residential house plan designed for a narrow, elongated plot (width of 25'-6"). The layout utilizes a vertical stack format consisting of a Ground Floor and a First Floor
The design efficiently handles the linear layout by introducing a dedicated 10'-0" wide side parking zone that spans almost the entire depth of the house, alongside strategic setbacks (varying from 1'-0" to 1'-9") to ensure ventilation and ease of access on all sides. An external-facing staircase structure at the front provides independent access to the floors, making it suitable for a multi-family setup or potential rental opportunities.
Plan highlights
Dedicated Parking
Compact Living Set
Expanded Living Space: Converts the footprint above the ground-floor parking into active residential space, transforming the layout into a much larger flat.
Liaison Clearance Notice
All structural parameters should be verified against local municipal development authorities before launching column layout adjustments.
Micro-Climatic Wind Patterns & Light Filtration
The facing direction and room zoning are planned to balance sunlight control, daily movement, and functional circulation.
Floor Layout & Share Metrics
| Zoning Quadrant | Floor Designation | Area Share | Structural Load Type | Civil Est. Share |
|---|---|---|---|---|
| Formal Living, Family Living, Kitchen, Dining, Guest Bedroom, Two Car Parking | Ground Floor | 24.60x48.6 sq.ft | Villa | 50-80 Lakhs |
| Master Suite, Two Bedrooms, Study, Balconies, Family Lounge | First Floor | 24.60x48.6 sq.ft | Villa | 50-80 Lakhs |
Floor Drawings & Spatial Program
Review floor-wise drawing references and room zoning before discussing civil execution, interiors, and local approval refinements.
Ground Floor
First Floor
Level 01
Ground Floor
Level 02
First Floor
